How to generate a crash dump for Windows (only for MSVC compiles)

Many of you may know that creating memory dumps under windows is a pain, as the project "Debug" is not working as intended and is bulky etc. Well this tutorial will show you how create a crash dump in "Release" settings. This will not alter the server performance, so please feel free to use it with your dedicated servers.

What is a Crash Memory Dump?
A crash memory dump is basically a way to retrace what has happened in the event of a program "crash". The dmp holds information about call stack and memory states at the time of the crash. This is extremely useful for Developers in order to identify and fix crash bugs that so many people complain about.

Requirements:

Step 1:
Open the project vc10/The Forgotten Server.sln file. If you have not set up your project for compiling, make sure you do that before continuing with this. Here is where you can find more information about initial setup under MSVC: http://otland.net/f479/compiling-msvc-compiling-forgotten-server-under-windows-easy-way-125178/

Step 2:
Now we need to make sure that the project is set to "Release"
(should be by default when you download the source, but lets make sure).

Step 3:
Next Go to The Forgotten Server project properties found here:



then set "Linker->Debugging->Generate Debug Info" to Yes (/DEBUG)



next we need to add the __EXCEPTION_TRACER__ to the definitions. Go to "C/C++->Preprocessor->Preprocessor Definitions" and click edit.



Copy & paste __EXCEPTION_TRACER__ anywhere in the box.



Step 4:
Go to "Build Solution" and wait for it to compile. Once it has finished compiling you need to make sure you copy the "Release/The Forgotten Server.pdb" file in the same file location as "Release/The Forgotten Server.exe" at all times. The .pdb file holds debugging and project state information that allows linking for debug configuration of your program. So it needs to be with the .exe file all the time if you want useful information on a crash.



Step 5:
Now when your server crashes a .mdmp file will be created, this is the useful file with the information you need!



To see the debug information just double click the file and wait for Visual Studio or Visual C++ to open. You will see a screen like this:



Click on "Debug with Native Only" then "Break" for information on the crash (it will open up files from your source code used to compile the server).



Step 6:

Crash Information! - Shows you where the fault has occurred in the source code.



The really useful information is under the "Call Stack" here:



and "Locals" (not always necessary)



and you are done! To report a crash, copy the "Call Stack" and "Locals" (if necessary). Just right click and select "Select All" then "Copy" and paste it into code tags under the project report section http://otland.net/project.php?projectid=2 be sure to give a clear description about what you were doing at the time of the crash and anything else you feel should be stated.

Report Example:
I right clicked on an NPC and the server crashed.

<NPC Lua/XML code here>

Call Stack:
Code:
>	The Forgotten Server.exe!Combat::canTargetCreature(Player * player, Creature * target)  Line 378	C++
 	The Forgotten Server.exe!Game::playerSetAttackedCreature(unsigned int playerId, unsigned int creatureId)  Line 3690	C++
 	The Forgotten Server.exe!boost::detail::function::void_function_obj_invoker0<boost::_bi::bind_t<bool,boost::_mfi::mf2<bool,Game,enum ReloadInfo_t,unsigned int>,boost::_bi::list3<boost::_bi::value<Game *>,boost::_bi::value<enum ReloadInfo_t>,boost::_bi::value<unsigned int> > >,void>::invoke(boost::detail::function::function_buffer & function_obj_ptr)  Line 154	C++
 	The Forgotten Server.exe!Task::operator()()  Line 34 + 0x62 bytes	C++
 	The Forgotten Server.exe!Dispatcher::dispatcherThread(void * p)  Line 75	C++
 	The Forgotten Server.exe!boost::detail::thread_data<boost::_bi::bind_t<void,void (__cdecl*)(void *),boost::_bi::list1<boost::_bi::value<void *> > > >::run()  Line 61 + 0x9 bytes	C++
 	The Forgotten Server.exe!boost::`anonymous namespace'::thread_start_function()  + 0x63 bytes	C++
 	The Forgotten Server.exe!_callthreadstartex()  Line 314 + 0x6 bytes	C
 	The Forgotten Server.exe!_threadstartex(void * ptd)  Line 292 + 0x5 bytes	C
 	kernel32.dll!75343677()
 	[Frames below may be incorrect and/or missing, no symbols loaded for kernel32.dll]
 	ntdll.dll!77409f02()
 	ntdll.dll!77409ed5()
Locals:
Code:
-		player	0x00000000 {VIPList=[...]() containerVec=[...]() invitationsList=[...]() ...}	Player *
+		Creature	{localMapCache=0x00000010 _tile=??? id=??? ...}	Creature
+		Cylinder	{...}	Cylinder
		playerCount	0	unsigned int
+		muteCountMap	[0]()	std::map<unsigned int,unsigned int,std::less<unsigned int>,std::allocator<std::pair<unsigned int const ,unsigned int> > >
+		autoList	{...}	AutoList<Player>
+		VIPList	[...]()	std::set<unsigned int,std::less<unsigned int>,std::allocator<unsigned int> >
+		containerVec	[...]()	std::vector<std::pair<unsigned int,Container *>,std::allocator<std::pair<unsigned int,Container *> > >
		invitationsList	[...]()	std::list<unsigned int,std::allocator<unsigned int> >
		storedConditionList	[...]()	std::list<Condition *,std::allocator<Condition *> >
+		depots	[...]()	std::map<unsigned int,std::pair<Depot *,bool>,std::less<unsigned int>,std::allocator<std::pair<unsigned int const ,std::pair<Depot *,bool> > > >
+		transferContainer	{maxSize=??? serializationCount=??? totalWeight=??? ...}	Container
		marriage	CXX0030: Error: expression cannot be evaluated
		balance	CXX0030: Error: expression cannot be evaluated
+		rates	0x000003e8	double [9]
+		talkState	0x00000430	bool [13]
+		inventoryAbilities	0x0000043d	bool [11]
		pzLocked	CXX0030: Error: expression cannot be evaluated
		saving	CXX0030: Error: expression cannot be evaluated
		isConnecting	CXX0030: Error: expression cannot be evaluated
		requestedOutfit	CXX0030: Error: expression cannot be evaluated
		outfitAttributes	CXX0030: Error: expression cannot be evaluated
		addAttackSkillPoint	CXX0030: Error: expression cannot be evaluated
		mounted	CXX0030: Error: expression cannot be evaluated
		pvpBlessing	CXX0030: Error: expression cannot be evaluated
		operatingSystem	CXX0030: Error: expression cannot be evaluated
		accountManager	CXX0030: Error: expression cannot be evaluated
		managerSex	CXX0030: Error: expression cannot be evaluated
		lastAttackBlockType	CXX0030: Error: expression cannot be evaluated
		chaseMode	CXX0030: Error: expression cannot be evaluated
		fightMode	CXX0030: Error: expression cannot be evaluated
		secureMode	CXX0030: Error: expression cannot be evaluated
		tradeState	CXX0030: Error: expression cannot be evaluated
		guildLevel	CXX0030: Error: expression cannot be evaluated
		blessings	CXX0030: Error: expression cannot be evaluated
		maxWriteLen	CXX0030: Error: expression cannot be evaluated
		sex	CXX0030: Error: expression cannot be evaluated
		mailAttempts	CXX0030: Error: expression cannot be evaluated
		premiumDays	CXX0030: Error: expression cannot be evaluated
		soul	CXX0030: Error: expression cannot be evaluated
		soulMax	CXX0030: Error: expression cannot be evaluated
		vocationId	CXX0030: Error: expression cannot be evaluated
		groupId	CXX0030: Error: expression cannot be evaluated
		managerNumber	CXX0030: Error: expression cannot be evaluated
		managerNumber2	CXX0030: Error: expression cannot be evaluated
		purchaseCallback	CXX0030: Error: expression cannot be evaluated
		saleCallback	CXX0030: Error: expression cannot be evaluated
+		varSkills	0x000004a0	int [7]
+		varStats	0x000004bc	int [5]
		messageBuffer	CXX0030: Error: expression cannot be evaluated
		bloodHitCount	CXX0030: Error: expression cannot be evaluated
		shieldBlockCount	CXX0030: Error: expression cannot be evaluated
		shootRange	CXX0030: Error: expression cannot be evaluated
		clientVersion	CXX0030: Error: expression cannot be evaluated
		messageTicks	CXX0030: Error: expression cannot be evaluated
		idleTime	CXX0030: Error: expression cannot be evaluated
		accountId	CXX0030: Error: expression cannot be evaluated
		lastIP	CXX0030: Error: expression cannot be evaluated
		level	CXX0030: Error: expression cannot be evaluated
		levelPercent	CXX0030: Error: expression cannot be evaluated
		magLevel	CXX0030: Error: expression cannot be evaluated
		magLevelPercent	CXX0030: Error: expression cannot be evaluated
		damageImmunities	CXX0030: Error: expression cannot be evaluated
		conditionImmunities	CXX0030: Error: expression cannot be evaluated
		conditionSuppressions	CXX0030: Error: expression cannot be evaluated
		nextStepEvent	CXX0030: Error: expression cannot be evaluated
		actionTaskEvent	CXX0030: Error: expression cannot be evaluated
		walkTaskEvent	CXX0030: Error: expression cannot be evaluated
+		lossPercent	0x0000051c	unsigned int [5]
		guid	CXX0030: Error: expression cannot be evaluated
		editListId	CXX0030: Error: expression cannot be evaluated
		windowTextId	CXX0030: Error: expression cannot be evaluated
		guildId	CXX0030: Error: expression cannot be evaluated
		rankId	CXX0030: Error: expression cannot be evaluated
		promotionLevel	CXX0030: Error: expression cannot be evaluated
		town	CXX0030: Error: expression cannot be evaluated
		skullEnd	CXX0030: Error: expression cannot be evaluated
		lastLogin	CXX0030: Error: expression cannot be evaluated
		lastLogout	CXX0030: Error: expression cannot be evaluated
		lastLoad	CXX0030: Error: expression cannot be evaluated
		lastPong	CXX0030: Error: expression cannot be evaluated
		lastPing	CXX0030: Error: expression cannot be evaluated
		nextAction	CXX0030: Error: expression cannot be evaluated
		lastMountAction	CXX0030: Error: expression cannot be evaluated
		lastHitOffMount	CXX0030: Error: expression cannot be evaluated
		stamina	CXX0030: Error: expression cannot be evaluated
		experience	CXX0030: Error: expression cannot be evaluated
		manaSpent	CXX0030: Error: expression cannot be evaluated
		lastAttack	CXX0030: Error: expression cannot be evaluated
		lastMail	CXX0030: Error: expression cannot be evaluated
+		skills	0x000005c0	unsigned __int64 [7][3]
		inventoryWeight	CXX0030: Error: expression cannot be evaluated
		capacity	CXX0030: Error: expression cannot be evaluated
+		managerChar	0x00000678 <Bad Ptr>	char [100]
+		managerString	{...}	std::basic_string<char,std::char_traits<char>,std::allocator<char> >
+		managerString2	{...}	std::basic_string<char,std::char_traits<char>,std::allocator<char> >
+		account	{...}	std::basic_string<char,std::char_traits<char>,std::allocator<char> >
+		password	{...}	std::basic_string<char,std::char_traits<char>,std::allocator<char> >
+		name	{...}	std::basic_string<char,std::char_traits<char>,std::allocator<char> >
+		nameDescription	{...}	std::basic_string<char,std::char_traits<char>,std::allocator<char> >
+		specialDescription	{...}	std::basic_string<char,std::char_traits<char>,std::allocator<char> >
+		guildName	{...}	std::basic_string<char,std::char_traits<char>,std::allocator<char> >
+		rankName	{...}	std::basic_string<char,std::char_traits<char>,std::allocator<char> >
+		guildNick	{...}	std::basic_string<char,std::char_traits<char>,std::allocator<char> >
+		loginPosition	{x=??? y=??? z=??? }	Position
+		itemsLight	{level=??? color=??? }	LightInfo
+		backpack	(..., ...	std::pair<Container *,int>
		vocation	CXX0030: Error: expression cannot be evaluated
		client	CXX0030: Error: expression cannot be evaluated
		walkTask	CXX0030: Error: expression cannot be evaluated
		party	CXX0030: Error: expression cannot be evaluated
		group	CXX0030: Error: expression cannot be evaluated
+		inventory	0x00000820	Item * [11]
		tradePartner	CXX0030: Error: expression cannot be evaluated
		tradeItem	CXX0030: Error: expression cannot be evaluated
		writeItem	CXX0030: Error: expression cannot be evaluated
		editHouse	CXX0030: Error: expression cannot be evaluated
		shopOwner	CXX0030: Error: expression cannot be evaluated
		weapon	CXX0030: Error: expression cannot be evaluated
+		forceWalkthrough	[...]()	std::vector<unsigned int,std::allocator<unsigned int> >
+		revengeList	[...]()	std::vector<unsigned int,std::allocator<unsigned int> >
+		attackedSet	[...]()	std::set<unsigned int,std::less<unsigned int>,std::allocator<unsigned int> >
		shopOffer	[...]()	std::list<ShopInfo,std::allocator<ShopInfo> >
		invitePartyList	[...]()	std::list<Party *,std::allocator<Party *> >
+		outfits	[...]()	std::map<unsigned int,Outfit,std::less<unsigned int>,std::allocator<std::pair<unsigned int const ,Outfit> > >
		learnedInstantSpellList	[...]()	std::list<std::basic_string<char,std::char_traits<char>,std::allocator<char> >,std::allocator<std::basic_string<char,std::char_traits<char>,std::allocator<char> > > >
+		warMap	[...]()	std::map<unsigned int,War_t,std::less<unsigned int>,std::allocator<std::pair<unsigned int const ,War_t> > >
-		target	0x00393628 {localMapCache=0x00393638 _tile=0x00000000 id=0 ...}	Creature *
+		AutoId	{autoId=0 count=1000 list=[0]() ...}	AutoId
		Thing	CXX0030: Error: expression cannot be evaluated
+		localMapCache	0x00393638	bool [23][23]
+		_tile	0x00000000 {qt_node=??? ground=??? pos={...} ...}	Tile *
		id	0	unsigned int
		removed	false	bool
		isMapLoaded	false	bool
		isUpdatingPath	false	bool
		checked	false	bool
+		storageMap	[0]()	std::map<std::basic_string<char,std::char_traits<char>,std::allocator<char> >,std::basic_string<char,std::char_traits<char>,std::allocator<char> >,std::less<std::basic_string<char,std::char_traits<char>,std::allocator<char> > >,std::allocator<std::pair<std::basic_string<char,std::char_traits<char>,std::allocator<char> > const ,std::basic_string<char,std::char_traits<char>,std::allocator<char> > > > >
		checkVector	0	int
		health	0	int
		healthMax	0	int
		healthMin	0	int
		mana	0	int
		manaMax	0	int
		hideName	false	bool
		hideHealth	false	bool
		cannotMove	false	bool
		speakType	MSG_NONE	MessageClasses
+		currentOutfit	{lookType=0 lookMount=0 lookTypeEx=0 ...}	Outfit_t
+		defaultOutfit	{lookType=0 lookMount=0 lookTypeEx=0 ...}	Outfit_t
+		masterPosition	{x=0 y=0 z=0 }	Position
+		lastPosition	{x=0 y=0 z=0 }	Position
		masterRadius	0	int
		lastStep	0	unsigned __int64
		lastStepCost	0	unsigned int
		baseSpeed	0	unsigned int
		varSpeed	0	int
		skillLoss	false	bool
		lootDrop	LOOT_DROP_FULL	lootDrop_t
		skull	SKULL_NONE	Skulls_t
		partyShield	SHIELD_NONE	PartyShields_t
		guildEmblem	EMBLEM_NONE	GuildEmblems_t
		direction	NORTH	Direction
		conditions	[0]()	std::list<Condition *,std::allocator<Condition *> >
+		internalLight	{level=0 color=0 }	LightInfo
+		master	0x00000000 {localMapCache=0x00000010 _tile=??? id=??? ...}	Creature *
		summons	[0]()	std::list<Creature *,std::allocator<Creature *> >
+		followCreature	0x00000000 {localMapCache=0x00000010 _tile=??? id=??? ...}	Creature *
		eventWalk	0	unsigned int
		cancelNextWalk	false	bool
		listWalkDir	[0]()	std::list<enum Direction,std::allocator<enum Direction> >
		walkUpdateTicks	0	unsigned int
		hasFollowPath	false	bool
		forceUpdateFollowPath	false	bool
+		attackedCreature	0x00000000 {localMapCache=0x00000010 _tile=??? id=??? ...}	Creature *
+		damageMap	[0]()	std::map<unsigned int,Creature::CountBlock_t,std::less<unsigned int>,std::allocator<std::pair<unsigned int const ,Creature::CountBlock_t> > >
+		healMap	[0]()	std::map<unsigned int,Creature::CountBlock_t,std::less<unsigned int>,std::allocator<std::pair<unsigned int const ,Creature::CountBlock_t> > >
		eventsList	[0]()	std::list<CreatureEvent *,std::allocator<CreatureEvent *> >
		blockCount	0	unsigned int
		blockTicks	0	unsigned int
		lastHitCreature	0	unsigned int
		lastDamageSource	COMBAT_NONE	CombatType_t
		targetEvents	[0]()	std::list<CreatureEvent *,std::allocator<CreatureEvent *> >
		deny	false	bool
Hope this helps all the Windows users out there! These are important for the TFS Devs to help make it more stable!

So please remember to post necessary crash reports to the team!

Last edited:

kornholi

Administrator
Staff member
Administrator
Joined
May 28, 2007
Messages
1,017
Best answers
0
Reaction score
61
Location
Chicago, USA
Why are you changing from Debug to Release and enabling Debug mode?


Doggynub

LUA / C++
Joined
Sep 28, 2008
Messages
2,541
Best answers
0
Reaction score
181
Isnt there boost files needed for dbg?

OP
BeniS

BeniS

Intermediate OT User
Joined
Aug 8, 2009
Messages
1,850
Best answers
0
Reaction score
183
Location
New Zealand
Why are you changing from Debug to Release and enabling Debug mode?
Debug mode doesn't work properly yet and is very bulky. Please read the description, this is just for creating memory dumps.

EDIT: Just realized I forgot one part in Step 3

We need to add the __EXCEPTION_TRACER__ to the definitions. Go to "C/C++->Preprocessor->Preprocessor Definitions" and click edit.



Copy & paste __EXCEPTION_TRACER__ anywhere in the box.


Last edited:

Elexonic

Excellent OT User
Joined
Jun 18, 2008
Messages
1,921
Best answers
0
Reaction score
56
VERY VERYYYYY GOD! Thanks You men!
Testing..

OP
BeniS

BeniS

Intermediate OT User
Joined
Aug 8, 2009
Messages
1,850
Best answers
0
Reaction score
183
Location
New Zealand
try copying the vc100.pdb file too


dgprado

Member
Joined
Apr 5, 2009
Messages
789
Best answers
0
Reaction score
18
Location
Patria Amada Brasil
shit shit shit ;// sorry but i really need this and dont work for me, someone are crashing my server and i make no idea how can he make this.

Can you compile for me the rev 4849 with war system and correct __EXCEPTION_TRACER__ plz ?


Evelyssz

Banned User
Joined
Nov 22, 2011
Messages
28
Best answers
0
Reaction score
0
Can you make a crash dump with devcpp 4.992? I dont think so =(

OP
BeniS

BeniS

Intermediate OT User
Joined
Aug 8, 2009
Messages
1,850
Best answers
0
Reaction score
183
Location
New Zealand
Mod wanna sticky this? It is useful.

OP
BeniS

BeniS

Intermediate OT User
Joined
Aug 8, 2009
Messages
1,850
Best answers
0
Reaction score
183
Location
New Zealand
mod sticky this please... It is useful for both the team and members.

Last edited:

Premislao

Member
Joined
Sep 28, 2012
Messages
169
Best answers
0
Reaction score
1
Some screens dissappeared. Could u post them back? :/ Would this tell me why my server shuts down? I mean no error in tfs window is displayed, just windows popup window says close or find solution online and doesnt find it.


miroki

Excellent OT User
Joined
May 28, 2009
Messages
13
Best answers
0
Reaction score
0
Does it still works for the TFS 1.0? I`ve tried and had no success


danne3131

Active Member
Joined
Jun 26, 2008
Messages
376
Best answers
0
Reaction score
31
If this works can anyone reupload pics ? =)

Top
